DTL-6

168 in. x 163 in. x 54 in. (427 cm x 414 cm x 137 cm) Water Capacity 2055 gal 7779 L Dry Weight 3100 lbs 1406 kg Heater 5.5 kW - 60 Hz  (3.0 kW - 50 Hz)

DUAL TEMP STANDARD FEATURES: Warranty (Lifetime Structure, 7-year Surface, 5-year Parts, Labor, Electrical and Plumbing, 2-year cabinet)  Heater (5.5 kW North America (60 Hz) (3) Grab Rails Full Foam with ABS Bottom Advanced Digital Control System (Color LCD Panel) Mutli-language Interface (N/A on Variable Flow System)  6 in. Maximum Tapered ASTM Cover  12 V - 5 in. Spa Light

POOL SIDE  Dimensions 168 in. x 91 in. x 54 in.  Water Capacity 1680 gal  Dry Weight 2250 lbs  Heater 5.5 kW - 60 Hz

STANDARD FEATURES: (3) Grab Rails 12 V - 5 in. Spa Light Hi-Flo Circulation System BellagioFall Water Feature Quad Swim Jet System (N/A on Variable Flow System) (4) Directional 6 in. Swim Jets (2) 4.0 HP 1-Speed Swim Pumps (with Speed Control)

OPTIONAL FEATURES: Variable Flow Swift Water Trainer (2) 5.0 HP True Variable Speed Swim Pumps with Built-in Speed Control (4) Directional 6 in. Swim Jets Built-in WiFi Touch Screen LCD with Multiple Programmable Swim Workout Options Download App for Smart Device to Control Exercise Pool Wirelessly (No Wi-Fi Module needed) Stereo System  1) Advanced Integrated Streaming Fully Integrated Bluetooth WiFi App Streaming and Internet Radio (6) 3 in. Speakers (4 on spa, 2 on pool) Subwoofer  (Available Only on Variable Flow System)  LED Lighting DynaBrite (8) 2 in. Lights (1) 5 in. Light Illuminated Bellagio Fall [Illuminates (4) 6 in. Swim Jets (Available Only on Variable Flow System)]   Water Purification  1) Diamond AOP™  2) Crystal ProPure™ Ozone Mixing Chamber  3) Ozonator  4) Nature2® Cartridge   Heater Valves   Aquatic Training System  1) Stationary Resistant Swim  2) Rowing Bars and Resistant Cords

SPA SIDE  Dimensions 72 in. x 91 in. x 54 in.  Water Capacity 375 gal  Dry Weight 850 lbs  Heater 5.5 kW - 60 Hz

STANDARD FEATURES: Helix SS Jet Design 12 V - 3.5 in. Spa Light Hi-Flo Circulation System with Microfilter

OPTIONAL FEATURES: LED Lighting (Options) 1) DynaBrite LED (1) 3.5 in. (6) 2 in. LED Light Tranquility Fall Air Controls 2) DynaStar LED (1) 3.5 in.(4) 2 in. LED Light 3) Multicolor 10 LED  Stereo System 1) Premium Infinity® Sound System by Harman (N/A on Variable Flow System) Bluetooth Receiver AM/FM USB Auxiliary Input (4) 3 in. Speakers (2) 6.5 in. Exterior Speakers Power Subwoofer 2) Bluetooth® Music Experience (N/A on Variable Flow System) AM/FM USB Auxiliary Input (4) 3 in. Speakers Subwoofer 3) bba™2 Audio (N/A on Variable Flow System) Fully Integrated Bluetooth Audio Streaming (4) 3 in. Speakers Subwoofer Optional (2) 3 in. Patio Speakers (Stereo System 2, 3, and Advanced Integrated Streaming) Worldwide WiFi App Module Download App for Smart Device to Control Spa Wirelessly 18 in. Tranquility Fall Pump/Heater Valves Water Purification (Options) 1) Diamond AOP™ 2) Crystal ProPure™ Ozone Mixing Chamber 3) Ozonator 4) FROG® @ease™ with SmartChlor™++ 5) Nature2® Cartridge

182 in x 168 in x 54 in (462 cm x 427 cm x 137 cm) Water Capacity 2130 gal 8063 L Dry Weight 3197 lbs 1450 kg Heater 5.5 kW - 60 Hz  (3.0 kW - 50 Hz)

DUAL TEMP STANDARD FEATURES: Warranty (Lifetime Structure, 7-year Surface, 5-year Parts, Labor, Electrical and Plumbing, 2-year cabinet)  Heater (5.5 kW North America (60 Hz) (3) Grab Rails Full Foam with ABS Bottom Advanced Digital Control System (Color LCD Panel) Mutli-language Interface (N/A on Variable Flow System)  6 in. Maximum Tapered ASTM Cover  12 V - 5 in. Spa Light

POOL SIDE  Dimensions 168 in. x 91 in. x 54 in.  Water Capacity 1680 gal  Dry Weight 2250 lbs  Heater 5.5 kW - 60 Hz

STANDARD FEATURES: (3) Grab Rails 12 V - 5 in. Spa Light Hi-Flo Circulation System BellagioFall Water Feature Quad Swim Jet System (N/A on Variable Flow System) (4) Directional 6 in. Swim Jets (2) 4.0 HP 1-Speed Swim Pumps (with Speed Control)

OPTIONAL FEATURES: Variable Flow Swift Water Trainer (2) 5.0 HP True Variable Speed Swim Pumps with Built-in Speed Control (4) Directional 6 in. Swim Jets Built-in WiFi Touch Screen LCD with Multiple Programmable Swim Workout Options Download App for Smart Device to Control Exercise Pool Wirelessly (No Wi-Fi Module needed) Stereo System  1) Advanced Integrated Streaming Fully Integrated Bluetooth WiFi App Streaming and Internet Radio (6) 3 in. Speakers (4 on spa, 2 on pool) Subwoofer  (Available Only on Variable Flow System)  LED Lighting DynaBrite (8) 2 in. Lights (1) 5 in. Light Illuminated Bellagio Fall [Illuminates (4) 6 in. Swim Jets (Available Only on Variable Flow System)]   Water Purification  1) Diamond AOP™  2) Crystal ProPure™ Ozone Mixing Chamber  3) Ozonator  4) Nature2® Cartridge   Heater Valves   Aquatic Training System  1) Stationary Resistant Swim  2) Rowing Bars and Resistant Cords

SPA SIDE  Dimensions 91 in. x 91 in. x 54 in.  Water Capacity 450 gal  Dry Weight 947 lbs  Heater 5.5 kW - 60 Hz

STANDARD FEATURES: Helix SS Jet Design 12 V - 3.5 in. Spa Light Hi-Flo Circulation System with Microfilter Dual Footblaster Jets

OPTIONAL FEATURES: LED Lighting (Options) 1) DynaBrite LED (1) 3.5 in. (6) 2 in. LED Light Tranquility Fall Air Controls Clear Footblaster (Optional) 2) DynaStar LED (1) 3.5 in.(4) 2 in. LED Light 3) Multicolor 10 LED  Stereo System 1) Premium Infinity® Sound System by Harman (N/A on Variable Flow System) Bluetooth Receiver AM/FM USB Auxiliary Input (4) 3 in. Speakers (2) 6.5 in. Exterior Speakers Power Subwoofer 2) Bluetooth® Music Experience (N/A on Variable Flow System) AM/FM USB Auxiliary Input (4) 3 in. Speakers Subwoofer 3) bba™2 Audio (N/A on Variable Flow System) Fully Integrated Bluetooth Audio Streaming (4) 3 in. Speakers Subwoofer Optional (2) 3 in. Patio Speakers (Stereo System 2, 3, and Advanced Integrated Streaming) Worldwide WiFi App Module Download App for Smart Device to Control Spa Wirelessly 18 in. Tranquility Fall Pump/Heater Valves Water Purification (Options) 1) Diamond AOP™ 2) Crystal ProPure™ Ozone Mixing Chamber 3) Ozonator 4) FROG® @ease™ with SmartChlor™++ 5) Nature2® Cartridge
